Day & Night plan

Day & Night plan

Pictures



Color Template:

Click on this link to open the colorizers page by Katzengrafik.

Template

Segel – Sail (Click link for PDF download link)
Seam allowance for the spine is included.

Specs:

Width: 152cm
Height: 68,5cm
Weight: 120gr

Icarex-sail

Seam width: 6mm
Stitch: 3step-Zigzag

Spine-reinforcement

Material: Dacron (laminated)
Measurements: check „Schablone.jpg“
Stitch: Zigzag

Stand-Off-reinforcement

Material: Dacron (laminated)
Measurements: check „Schablone.jpg“
Stitch: Zigzag

Upper-Spreader-reinforcement

Material: Dacron (self-glueing)
Measurements: 2€-piece

Center-T-reinforcement

Material: Dacron (laminated)
Measurements: check „Schablone.jpg“
Stitch: Zigzag
How to: Distance between the peak of the reinforcement and the nose is 40cm

Trailing Edge

Material: Spinnaker ribbon
Measurements: 2,5cm * 100cm (per side)
Stitch: Zigzag

Leading Edges

Material: Dacron
Measurements: 5cm * 110cm (incl. 5cm to fold at the wing-tip)
Stitch: Zigzag
How to: Fold 5cm at the end of the LE and double it to reinforce the area.

Nose

Material: Bisonyl
Measurements: check „Schablone.jpg“
Stitch: Straight, check „Nase.jpg“

Bridle

Material: Climax 35daN
Measurements: check „Waage.jpg“

Cut-outs and connectors

Check „Ausschnitte I.jpg“, „Ausschnitte II.jpg“ and „Kreuzposition.jpg“

Rods

Lower spreaders: 1m * 5mm Exel
Leading-Edges: 1m * 4mm Exel
Spine & Upper spreader: 1m * 4mm Exel
Stand-Offs: 3mm CFK
Spine: 64cm
Upper spreader: 36cm
Leading Edge: 100cm
Lower spreader: 50cm (Lay-In: 5cm * 3mm CFK)
Stand-Offs: 19,2cm from the lower edge of the LS to the sail

Links

Topic on german Drachenforum: LINK.
